Water Cooling Raycus 1500W Handheld Fiber Laser Welding Machine 4 In 1 For Metal Aluminum
| laser source | RAYCUS; MAX; BWT; RECI |
| water cooling system | built-in water chiller |
| laser gun | Chaoqiang SUP series |
| power optional | 1000W; 1500W; 2000W |
| wire feeder | single wire feeder; dual wire feeder |
| customized | color; LOGO; OEM service |
- Advantages of handheld laser welding machines
1. High Precision Welding
Handheld laser welding offers micron-level accuracy, ideal for delicate or complex parts. The concentrated heat input minimizes distortion, ensuring clean and precise seams.
2. Flexible & User-Friendly Operation
Unlike traditional welders, handheld laser devices are portable and easy to maneuver, allowing welding in tight spaces or curved surfaces without fixtures.
3. High Efficiency & Energy Saving
Laser welding achieves speeds 3-10x faster than TIG/MIG methods, with lower power consumption and minimal material waste, reducing production costs.
4. Multi-Material Compatibility
Works seamlessly on stainless steel, aluminum, copper, brass, and dissimilar metal combinations with minimal spatter or oxidation.
5. Aesthetic Welds with Minimal Post-Processing
The non-contact process produces smooth, crack-free seams, often eliminating the need for grinding or polishing—ideal for visible joints in consumer products.
Laser Welding head: (SUP 21T/23T)
We have a variety of brand models to choose from, the picture example is Super strong Weiye 23T, the head of the welding, cleaning, cutting multiple functions in one.
SUP23T
| input voltage (V) | 220V±10% AC 50/60Hz |
| Installation environment | Flat, no vibration and impact |
| Working environment temperature: (℃) | 10～40 |
| Working environment humidity: (%) | ＜70 |
| cooling-down method | hydrocooling |
| Applicable wavelength | 1064nm(±10nm) |
| Applicable power | ≤3000W |
| alignment | D16*4.5/F60 |
| focus | D20*4.5/F150 |
| reflex | 30x14xT2 |
| Protection mirror specifications | D18*T2 |
| Maximum air pressure support | 15Bar |
| Focus of vertical adjustment range | ±10mm |
| Scan width-weld | 0~8mm |
| Scan Width-Wash | F150-0~30mm |
| F400-0~60mm |
| F800-0~120mm |
| The net weight of the gun | 0.75kg |
SUP21T
| input voltage (V) | 220V±10% AC 50/60Hz |
| Installation environment | Flat, no vibration and impact |
| Working environment temperature: (℃) | -10～50℃ |
| Working environment humidity: (%) | ＜70 |
| cooling-down method | hydrocooling |
| Applicable wavelength | 1064nm(±10nm) |
| Applicable power | ≤3000W |
| alignment | D16/F60 |
| focus | D20/F150 |
| reflex | 30x14xT2 |
| Protection mirror specifications | D18*T2 |
| Maximum air pressure support | 15Bar |
| Focus of vertical adjustment range | ±10mm |
| Scan width-weld | 0~8mm |
| Scan Width-Wash | F150-0~30mm |
| F400-0~60mm |
| F800-0~120mm |
| The net weight of the gun | 0.75kg |
Wire feeder:
single wire feeder and double wire feeder, according to the thickness of the processing material weld width to choose
Laser source: (RAYCUS SERIES)
According to the thickness of the welding plate selection, usually we have 1000W,1500W,2000W and 3000W
JPTECH LASER was established in 2018, specializing in the production and sales of industrial laser equipment enterprises.Main products: fiber laser welding machine, robot automatic laser welding machine, fiber laser marking machine, CO2 laser marking machine, UV laser marking machine, laser cutting machine, laser cleaning machine and other products. Companies learn from domestic and foreign advanced technology, relying on years of market accumulation has established a stable laser equipment technology sales integration, industrial automation control and research and development of technical service team.
